Metal glazed roof tile roll forming machine Line

  • Metal glazed roof tile roll forming machine Line
  • Metal glazed roof tile roll forming machine Line
  • Metal glazed roof tile roll forming machine Line
  • Metal glazed roof tile roll forming machine Line

Metal glazed roof tile roll forming machine Line

Product Description

  Metal glazed roof tile Roll Forming Machine Line



Product Description



Glazed tile / Vitreous tiles roll Forming Machine

(1) Material of frame : (high grade) 250mm H shape steel welding

(2) Thickness of middle plate : 12mm

(3) Step of forming roller : 10steps

(4) Diameter of shaft (solid shaft)74mm

(5) Material of shaft (solid shaft)(high grade) 45# Steel, quenched and tempered treatment,hard chromize

coated 0.05-0.07mm

(6) Drive type of roll forming machine : drive by chain

(7) Chain : 25.4 mm (high grade)

(8) Bearing : 6210 (high grade)

(9) Reducer : 5# cycloid reducer (high grade)

(10) Power of main motor : 3KW

(11) Voltage : 380V/50Hz/3phase

(12) Line speed : about 9 m/min

(13) Feeding width : 1000mm or 1200mm

(14) Suitable coil thickness : accepted thickness for aluminum coil is 0.3mm-0.9mm.

                      accepted thickness for steel coil is 0.3mm-0.6mm.

(15) Motor power of hydraulic station : 3kw

(16) Oil pump of hydraulic station : gear oil pump (high grade)

(17) Hydraulic cutting: cutting controlled by PLC

(18) Accuracy of cutting : +/- 2mm

(19) Razor blades material : Cr12, quenching 58-62 °.

(20) Appearance size of main forming machine : 6m (long)*1.3m (width) *1.5m (height)

(21) Weight of main forming machine : about 4.5T

(22) Electrically controlled system : entire machine controlled by PLC































Company Information





Factory







ISO CERTIFICATION

BOTOU HUATONG CORRUGATED MACHINERY MANUFACTURING CO.,LTD

 O ur company is a leading manufacturer of roll Forming Machinery in China. We have many years' experience in designing, researching and producing various Roll Forming machines. We own a highly qualified and professional team in the design, scientific research, production, sales and after-sales services. Our company has strong technical force, 150 professional talents in related fields, 20 employees with senior professional titles, more than 50 employees with intermediate professional titles and 80 technicians. We have advanced production equipment, strong production capacity and perfect after-sales service system. Our enterprise has passed ISO9001:2000 international quality system certification. We carry out ISO9001 standards strictly in the course of production. We provide customers with excellent products and integrated services. Our product and brand have been approved unanimous by all customers and gained a good reputation from customers in domestic and overseas markets, therefore so many customers are willing to keep long-term and friendly cooperation with us. Our products not only extend all over domestic markets but also enter international market. At present, our products have been exported to many countries and regions, such as Russia, Saudi Arabia, Canada, Spain, Australia, New Zealand, Singapore, Korea, Sri Lanka, Malaysia, Nigeria, Armenia, Tanzania, Azerbaijan, Kazakhstan, Brazil, Mexico, etc. We are the specialized manufacturer in producing roof board and wall board Forming Machine series, Glazed Tile Forming Machine series, floor plate forming machine series, c and z steel product forming machine series, double-deck color Steel Tile Forming Machine series, roll shutter door forming machine series, clip core board line series, ridge tile and attached equipment forming machine series, curving machine series, checking level machine series, plate cut-off equipment series, highway guardrail equipment series, uncoiler or stacker series, drainpipe forming machine series, plate Shearing machine, plate bending machine and slitter machine series, other supporting facilities and so on. At the same time, we can customize the design and fabrication on the particular type of machine for customers. Our technician team always pays close attention to and keeps up with the developing trend of technology and adopts new technologies into our products, so our products have characteristics of high efficiency, high precision, high, flexibility and low process wastage. These characteristics have gained high competitive strength for our products. All of our products are popular to steel building industry for light construction, reasonable design and update style. Customer's benefit is the first. We know deeply that our development and success come from development and success of our customer. We run this mind through the whole process from design products to after-sales service. We design and produce product according to the demands and requests of customers to help them improve efficiency, reduce cost and increase competitive strength. Our perfect after-sales service ensures we can supply high quality service to every customer. We will insist on the principle of "Customer is god, Quality is life, Service gains trust, Innovation leads to development, Prestige casts brands, Brilliant casts resplendence " to supply satisfying products and high quality services to every customer. Warmly welcome to visit our factory, we sincerely hope to establish long and good business relationship with you, looking forward to creating a beautiful future with you! Welcome to contact us for more information.

Company Info

  • Company Name: BOTOU HUATONG CORRUGATED MACHINERY MANUFACTURING CO.,LTD
  • Product/Service: roll forming machine , curving machine , bending machine , cutting machine , slitting machine
  • Contact Person: Mr. SONG
  • Tel: 86-317-8189769
