Latest Technology C Purlin Channel Roll Forming Machine
Basic Info
Model No.: Customized
Product Description
Latest Technology C Purlin Channel Roll Forming Machine
Product Description
(1) The structure is simple and the appearance of the machine is beautiful because we adopt the shape-steel structure and process as a whole after welding. it has the ability of strong loading and stable operation when running the machine.
2) All the components of machine are from brand-famous enterprise so that they ensure the machine normal function very effectively.
3) We adopt the automatic length-fixed forming and cutting to guarantee the length to be precise and the finished product clear without deforming .
4) It is very easy to install the equipment and suitable for producing in the factory.
5) The machine has features of low noise and high efficiency.
Main parameters
1 | Roll Forming Machine |
1.1 | Main forming: 20 steps |
1.2 | Forming speed: 10-15 m/min (not include punching and cutting time) |
1.3 | Main dimension: 10000 x 1800 x 1800mm (L x W x H) |
1.4 | Total weight: 13000kg |
1.5 | Main motor: 15kw |
1.6 | Feeding, leveling motor power: 4KW |
1.7 | Hydraulic pressure: 12-16MPa |
1.8 | Hydraulic power: 5.5KW |
1.9 | Feeding & guiding: two sets (GCr15, 9CrSi, Forged steel hardened and around to 58 to 60 HRC & Hard chrome Plated) |
Leveling: one set, seven rollers. (GCr15, 9CrSi, Forged steel hardened and around to 58 to 60 HRC & Hard chrome Plated) | |
1.10 | Adjust the size: control by PLC system |
1.11 | Material of rollers: GCr15, 9CrSi, Forged steel hardened and around to 58 to 60 HRC |
1.12 | Material of shaft: number 45 forge steel hardening and tempering |
1.13 | Transmission: By 1 inch double chain |
2 | Purlin specifications: |
Steel thickness (t): from 1,5 mm to (at least) 3,0 mm; Profile height (H): from 75 mm to (at least) 300 mm; Flange width (b): from 40 mm to (at least) 90 mm; Flange height (c): from 10 mm to (at least) 20 mm; Maximum hole diameter deviation: +2 mm/-0 mm Minimum finished product length: at least 1500 mm; Maximum finished product length: at least 12000 mm; Length tolerance: ±1.5mm per each pieces |
Some Drawings
Packaging & Shipping
1.Packing:the main parts will be wrapped with plastic film the fixed to container by iron wires
2.Delivery:about 15days after receiving the full paymet
3.Port:Tianjin Port
Our Services
1. Any small problems will be solved at the most prompt time.
2. We always offer relateive technical support,quick response,all your inquire will replied within 24 hours.
3. We can delivery your goods within 25 workdays.
4. OEM service.
Company Information
Cangzhou dixin roll Forming Machinery co., ltd as a manufacturer since 1996, we are specialized in manufacturing color steel forming machine, light keel machine, c&z purline machine, Glazed Tile Forming Machine, welded tube mill, steel structural floor panel Roll Forming machine and so on. We can provide you one station, non-stop service. Our machines have been exported to 90 countries, such as Canada, South Korea, Russia, Holland, Sri Lanka, Malaysia, India, Brazil as so on. Our company insists on the service aim: Quality First, Credit First. We believe that we can make the future cooperation and achieve win-win.
Product Categories : CZ Purlin Roll Forming Machine
